Sectional doors
A popular solution for closing garages, characterised by functionality, aesthetics and high insulation. They consist of horizontal panels (sections) that move vertically upwards and then along the garage ceiling.
Choosing the right garage door is a decision that affects daily comfort of use and home safety. Thanks to the wide range of available solutions, everyone will find something to suit them — both in terms of functionality and aesthetics.
Key features
Door guide rails
Every garage has different spatial conditions. We offer three guide types adapted to the lintel height.
Panel types
Sectional doors are manufactured based on two panel types — standard 40 mm and thermal insulation 60 mm ThermicGATE.
Panel 40 mm
Standard
Sections with a thickness of 40 mm and a height of 500, 555 or 610 mm. Made of hot-dip galvanised steel sheet coated with polyester, filled with polyurethane foam with high insulation value.
Panel 60 mm
ThermicGATE
Sections with a thickness of 60 mm and a height of 500 mm. Made of galvanised steel Z100 and Z225, filled with polyurethane foam with very good insulating properties. U-value = 0.39 W/m²·K.
Drive types
We offer two types of electric drives — side and ceiling-mounted. Both enable remote control via remote controller.
Side-mounted drive
Space saving under the ceiling
Mounted on the side of the door — ideal when the space above the entrance is limited. Does not take up space under the garage ceiling.
Ceiling-mounted drive
Quiet and smooth operation
Mounted under the garage ceiling — particularly suitable for sectional doors. Ensures quiet and smooth operation as well as an aesthetic appearance.
Garage door control
Control and safety systems for garage doors — multi-channel remote control and photocells for obstacle detection.
SOMFY KEYGO io
Small, handy and robust 4-channel transmitter for controlling gate and roller shutter drives. Resistant to moisture and impact.
Somfy Photocells
Set of transmitter + receiver to work with garage door drives. They detect obstacles in the light beam of the door and stop movement in the event of danger.
Panel patterns
Three embossing patterns — from smooth minimalism to the classic ribbed panel.
Without embossing
With one embossing
Ribbed panels
Panel colours
12 available finishes — from classic white to decorative wood-effect films.
White 9016
Golden Oak
Winchester
Walnut
Anthracite 7016 Matt
Anthracite 7016
Bog Oak
Black 9005M Matt
DB703 (7024M)
Woodec Honey Oak
Silver 9006
Brown 8014
The colour swatches and product visualisations shown above do not fully reflect the actual colours or the real material structure — they are intended only as an indicative visual reference of the final result.
Specifications
Technical parameters of sectional garage doors
| Parameter | Value |
|---|---|
| Door type | Sectional garage door |
| Panel thickness | 40 mm (Standard) / 60 mm (ThermicGATE) |
| U-value (60 mm) | 0.39 W/m²·K |
| Ψ between panels (60 mm) | 0.209 W/m·K |
| Section height (40 mm) | 500 / 555 / 610 mm |
| Section height (60 mm) | 500 mm |
| Track | RSC 200 / RES 350 / RSC 80 |
| Control | Manual / Electric drive with remote control |
| Panel patterns | 3 embossing patterns |
| Panel colours | 12 colours |
| Finger protection | Yes — finger pinch protection |
